Timer parameters

The definition of a timer depends on the following programming parameters:



• Enabled – option that enables the selected timer.



• Label – 20 character string that the control panel will use to identify the timer.





• Timeframe 1 / 2 – it is possible to program two timer activation slots.
  Fields are available for specifying the “ON” time and the “OFF” time of the selected timer.
  If you do not want to specify a time slot, leave the field empty.



• Year / Month / Day – fields to define the date of timer operation.
  For any day, month or year, select “Any”.

• Day of the week – options for specifying weekly recurrences. Valid only if “Year”, “Month” or “Day” are not specified.

• Holidays / No holidays – options to include / exclude the holidays to the list of days programmed for the timer (holidays).



• Actions on activation / deactivation – fields for selecting the action to be generated when the timer activates and deactivates (actions).
