DIVA

LED emergency lighting lamp with a compact and minimal design


Description

Products Range

DIVA

Products Typr

Lighting fixture

Versions

Standard, Self-Test, Bus Supervised, Central-Battery

Type

Maintained, (SA) - Non-Maintained (SE)

Technical specifications

Installation

Wall, ceiling

Power Supply

220/230Vac, 50-60Hz

Battery

LiFePO4 3,2V

Insulation class

II

Color

White RAL9003

Light source

LED

Color temperature

5700K

Screen

Polycarbonate welded by ultrasound

Additional info

Dedicated terminal for the inhibition function

Dedicated terminal for rest mode

IP Grade

IP IP42, IP65 (*)

IK Grade

IK IK07

Operating temperature

da 0° a 50°C

Compliant to standards

EN 55015, EN 60598-1, EN 60598-2-22,

EN 61000-3-2, EN 61000-3-3, EN 61347-1,

EN 61347-2-7, EN 61547, EN 62471

dimension (mm)

Width

230

Height

100

Depth

22,5

(*) The IP65 degree is obtained with an accessory kit that includes:
1) a seal
2) a tube-box connection
3) two plastic caps

Available versions Order codes Duration Battery LiFePO4 3.2V [Ah]
Mantained (SA) - Non mantained (SE) FLOW SE (lm) FLOW SA (lm) Recharge INICOM compatibility
Standard DVSE081542 1,5 h 0,6 SE 160 - 12 h -
DVSE110242 2 h - 3 h 1,5 SE 215 - 175 - 12 h -
DVSE181542 1,0 - 1,5 h 1,5 SE 435 - 330 - 12 h -
DVSA060342 3 h 0,6 SE/SA 80 115 12 h
DVSA081542 1,5 h 0,6 SE/SA 155 115 12 h
DVSA080342 3 h 1,5 SE/SA 145 145 6 h
DVSA110142 1 h 0,6 SE/SA 180 115 12 h
DVSA110242 2 h 1,5 SE/SA 195 195 6 h
DVSA110342 3 h 2 x 1,5 SE/SA 195 195 12 h
DVSA181542 1,5 h 1,5 SE/SA 340 195 6 h
DVSA180342 3 h 2 x 1,5 SE/SA 340 195 12 h
DVSA241542 1,5 h 2 x 1,5 SE/SA 415 240 12 h
Auto-test DVAA080342 3 h 1.5 SE/SA 145 145 6 h
DVAA110242 2 h 1.5 SE/SA 195 195 6 h
DVAA110342 3 h 2 x 1.5 SE/SA 195 195 12 h
DVAA180142 1 h 1.5 SE/SA 340 195 6 h
DVAA180242 2 h 2 x 1.5 SE/SA 340 195 12 h
DVAA241542 1,5 h 2 x 1.5 SE/SA 415 240 12 h
BUS supervised DVBA080342 3 h 1.5 SE/SA 145 145 6 h -
DVBA110242 2 h 1.5 SE/SA 195 195 6 h -
DVBA110342 3 h 2 x 1.5 SE/SA 195 195 12 h -
DVBA180142 1 h 1.5 SE/SA 340 195 6 h -
DVBA180242 2 h 2 x 1.5 SE/SA 340 195 12 h -
DVBA241542 1,5 h 2 x 1.5 SE/SA 415 240 12 h -
Central-battery DVLA080042 - - - - 145 - -
DVLA110042 - - - - 195 - -
DVLA180042 - - - - 340 - -
DVLA240042 - - - - 415 - -
